(**** TOOL HEAD TOOLS ****)
(T001 OD TURN - 55 )
(T002 OD GROOVE .125 )
(T003 CENTER DRILL 0.0938)
(T004 DRILL 1/8-Z 0.125)
(T005 MILL 1/8 - Z 0.125)
(T006 MILL 1/4 - Z 0.25)
(T007 FACE MILL 1.75)
(T008 SLANTED END MILL 0.25)
(T009 SPOT DRILL .5 0.5)
(T010 DRILL .375 0.375)
(T011 MILL 1/8 - X 0.125)
(T012 CUT-OFF )

G95 G90 G80 G64 G49 G40 G18 G0
G10.9 X1. (X DIAM)
G53 G0 X0 Y0
G53 Z0
M108
G53 B0.0
M107

N01 (TOOL 001 TURN FACE)
G90 G80 G64 G49 G18 G0
G10.9 X1. (DIAM PROGRAM)
G53 X0 Y0
G53 Z5.0 (TCH Z)
T001.1 M6 (OD TURN - 55)
M1
M901 (MAIN)
M202 (MAIN SPINDLE TURN MODE)
M108 (UNCLAMP B)
G53 G0 B90.0
M107 (CLAMP B)
G95 G54 G18 G0
G97 S669 M203
M8 (STD COOL HEAD)
G0 G95 X3.35 Z0.1
G92 S1600 R1
G96 S560 R1
X3.1376
Z0.
G1 X2.9376 F0.01088
X-0.0624
X-0.2624
G0 X3.35 Z0.1

N02 (TURN OD TURN 1)
Z0.05
G96 S560 R1
X3.05
G1 Z-3.0312
X3.35
G0 Z0.05
X2.85
G1 Z-1.1208
X3.0127 Z-1.2741
G3 X3.02 Z-1.2887 R0.0312
G1 Z-3.0312
X3.05
M30
